GPS Repeater Kit for Hangars

Features & Benefits

GPS solution supporting Global Navigation Satellite Systems (GNSS) including Glonass & Galileo High efficiency directional indoor re-transmitting antenna

  • Aircraft hangars
  • Border surveillance
  • Fire/Police stations
  • Tunnels
  • Data centers
  • Fleet management
  • Military bunkers

Description

Global Foxcom’s GNSS repeater solution is the ideal solution for re-transmitting GNSS signals indoors.

The repeater system provides seamless coverage inside a hangar enabling the testing of aircraft navigational systems without the need to move the aircraft out of the hangar.

The Repeater Kit consists of an Outdoor Unit (ODU), and/or an Indoor Unit (IDU), antennas, cables and a power supply (PS). Using top RF-Noise performance and a unique indoor directional RHCP antenna, the system provides better coverage, consumes less power and adds less distortion than compatible systems.

Global Foxcom offers optional fiber optic repeaters for remote and flexible placement of outdoor antennas. Users can enjoy the many benefits that optical fiber has to offer, such as low RF transmission loss, improved signal quality, lightning protection, safety and ease of installation.

RF Specification Value
Frequency Range – Bandwidth 1616-1626.5MHz
Noise Figure < 2dB
Amplitude Response @ Unity Gain 50dB variable
