10MHz Extractor / Inserter DCI


10MHz Extractor / Inserter is used to extract, and/or Insert a 10MHz reference signal and DC onto an L-Band path in VSAT systems.

RF Specification Value
Frequency Range – Bandwidth 950 – 2150MHz
L-Band Insertion Loss <1dB
L Band Return Loss >15dB
10MHz Insertion Loss <0.5dB
10MHz Rejection >90dB
Max DC Voltage 75V
Max DC Current 4 Amps
