Description
10MHz Extractor / Inserter is used to extract, and/or Insert a 10MHz reference signal and DC onto an L-Band path in VSAT systems
10MHz Extractor / Inserter DCB
| RF Specification | Value |
| Frequency Range – Bandwidth | 950 – 2150MHz |
| L-Band Insertion Loss | <1dB |
| L Band Return Loss | >15dB |
| 10MHz Insertion Loss | <0.5dB |
| 10MHz Rejection | >90dB |
